₹112,899.00
FRAME
Alpha Gold Aluminium, tapered head tube, internal derailleur and dropper post routing, rack and kickstand mount, Boost141, 5 mm QR
FORK
Size: XS
RockShox Judy SL, Solo Air spring, TurnKey lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Lite, 80 mm travel
Size: S
RockShox Judy SL, Solo Air spring, TurnKey lockout, tapered steerer, Boost110, 15 mm Maxle Lite, 100 mm travel
Size: M, M/L, L, XL, XXL
RockShox Judy SL, Solo Air spring, TurnKey lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 100 mm travel
Max compatible fork travel 120mm (XS: 100mm)
FRONT HUB
Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle
REAR HUB
Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost141, 5 mm QR
RIM
Size: XS, S
Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve
Size: M, M/L, L, XL, XXL
Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve
Size: M, M/L, L, XL, XXL
Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve
TYRE
Size: XS, S
Maxxis Ardent Race, tubeless, EXO casing, folding bead, 60 tpi, 27.5x2.35"
Size: M, M/L, L, XL, XXL
Maxxis Ardent Race, tubeless, EXO casing, folding bead, 60 tpi, 29x2.35"
Tyre part Bontrager TLR sealant, 180 ml/6 oz
Rim strip Bontrager TLR
Max tyre size Frame: 27.5x2.80" or 29x2.40" Fork: See manufacturer
SHIFTER
Shimano Deore M6100, 12-speed
REAR DERAILLEUR
Shimano XT M8100, long cag
FRONT DERAILLEUR
NA
CRANKSET
Size: XS, S, M
Shimano MT511, 30T steel ring, 52 mm chainline, 170 mm length
Size: M/L, L, XL, XXL
Shimano MT511, 30T steel ring, 52 mm chainline, 175 mm length
*Bottom bracket Size: XS, S, M, M/L, L, XL, XXL
BB-SET
Shimano BB-MT501 BSA
Size: XS, S, M, M/L, L, XL, XXL
Shimano SM-BB52, 73 mm, threaded external bearing
CHAIN
Shimano Deore M6100, 12-speed
CASSETTE
Shimano Deore M6100, 10-51, 12-speed
BRAKES
Tektro / 6 bolts / F&R 160mm
PEDAL
Size: XS, S, M, M/L, L, XL, XXL
Wellgo VPE-536
Size: XS, S, M, M/L, L, XL, XXL
VP-536 nylon platform
SADDLE
Bontrager Arvada, steel rails, 138 mm width
HANDLEBAR
Size: XS
Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width
Size: S, M
Bontrager alloy, 31.8 mm, 5 mm rise, 720 mm width
Size: M/L, L, XL, XXL
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
H'STEM
Size: XS, S
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length
Size: M, M/L
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length
Size: L
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
Size: XL, XXL
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
SEATPOST
Size: XS, S
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Size: M
Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm length
Size: M/L, L, XL, XXL
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
HEADSET
Semi-integrated, loose ball bearing, 1-1/8" top, 1.5" bottom
BRAKES
Shimano MT200 hydraulic disc
*Brake rotor Size: XS, S, M, M/L, L, XL, XXL
Shimano RT26, 6-bolt,160 mm
Size: L, XL, XXL
Shimano RT26, 6-bolt,180 mm
Brake Set Shimano MT200 hydraulic disc
